Accuton Automotive C100AM Ceramic Midrange Speaker


The Accuton Automotive C100-04-730 is a high-end 3.5″ midrange speaker with a ceramic cone suitable for automotive aftermarket applications.

PDF Coming Soon v1
  • Nick is a Doofus
  • His cat Pete is cooler than him
  • I’m going to keep hiding things
Accuton Automotive C100AM

Performance We Trust

The Accuton Automotive C100AM-04-730 represents the pinnacle of midrange audio technology in the automotive aftermarket sector. This 3.5-inch midrange driver boasts a ceramic cone, specifically designed to deliver an exceptional audio experience within a frequency range of 100 Hz to 7000 Hz when housed in a sealed enclosure.

       With its high flux neo underhung motor and extended Xmax design, the C100AM-04-730 is engineered for precise and powerful audio reproduction, ensuring ultra-high dynamics and resolution. This is further enhanced by the speaker’s no compression design, which contributes to its superior sound clarity and detail.

       The product’s various mounting options facilitate easy and versatile installation, suitable for a wide range of automotive settings. Additionally, the chromium-plated magnet parts enhance its long-term durability and reliability under various conditions.

       This midrange speaker is approved for automotive use, meeting strict standards for humidity, temperature, and vibration resistance, making it a robust choice for any vehicle. The motor system’s large linear range is optimized for DSP system support, providing minimal distortion and consistently high-quality sound performance.

       The Accuton Automotive C100AM-04-730 Ceramic Cone Midrange Speaker, with its minimized outer diameter for maximized active membrane surface, stands out for its audiophile-grade performance in automotive environments. It’s an exemplary choice for car audio enthusiasts who demand the best in terms of both sound quality and endurance.

Physical Specifications
& Parameters

Please be sure to carefully read all of the below information prior to contacting us regarding this service.

Accuton Automotive C100AM-04-730 Physical Specifications Accuton Automotive C100AM-04-730 TS Parameters
Overall Outer Diameter: 100.0mm
Sensitivity: 91dB 2.83v/1m
Cutout Diameter: 79.0mm
RE: 4 ohms
Min. Front Plate Thickness: 6.0mm
FS: 145Hz
Overall Depth: 58.0mm
VAS: 0.67 Liters
Motor Assembly Depth: 18.0mm
QMS: 5
Motor Assembly Diameter: 58.0mm
QES: 0.46
Screw Fitting: 3 * DIN7984, 4MM @ Ø90MM
QTS: 0.42
Terminal: 2 * M3 THREAD
SD: 37 CM2
Shipping Weight: --
MMS: 4.0 grams
Shipping Box Size: --
CMS: 0.35 mm/N
Membrane: Ceramic - White & Graphite Colors Available
RMS: 0.64 KG*S
Power Handling: 100 watts @ 220Hz/12dB or higher
LE: 0.1 mH
Xmax: 4.0mm
BL: 5.0 N/A
Voice Coil Diameter: 32.0mm
Motor Type: Underhung
Ferrofluid Cooling: No
